MPC8358ECZQAGDDA

厂商：
Freescale
类别：
PowerQUICC II pro
包装：
Tray
封装：
PBGA-PGE 668 29SQ1.2P1.0
无铅情况/ROHS：
有铅
描述：
8358 PBGA ENCRP

我要询价我要收藏

  • 参数
  • 描述
  • 文档
参数 数值
速度 400MHz
处理器类型 MPC83xx PowerQUICC II Pro 32-Bit
电压 1.2V
安装类型 Surface Mount
Junction Operating Temperature (Min) (°C) -40
POQ Container BOX
Communication Protocol Ethernet / ATM
Core: Type e300
External Memory Supported DDR / DDR1 / DDR2 / DRAM / EPROM / SDRAM
Pb-Free No
Status Active
Export Control Classification Number (US) 5A002
Maximum Time at Peak Temperature (s) 40
MPQ Container TRAY
Ethernet 10/100/1000 BaseT
Package Material Plastic
Package Thickness (nominal) (mm) 1.200
REACH SVHC Freescale REACH Statement
Serial Interface - Number of Interfaces 1 / 1 / 2 / 1 / 1
Budgetary Price($US) 100 @ $39.82 each
RoHS Compliant No
Device Weight (g) 6.06920
External Bus Interface Local / PCI
Co Processor Type QUICC
Mounting Style Surface Mount
Package Length (nominal) (mm) 29.000
Package Width (nominal) (mm) 29.000
Part Number MPC8358ECZQAGDDA
Preferred Order Quantity (POQ) 180
Serial Interface - Type HDLC / I2C / SPI / UART / USB
Floor Life 168 HOURS
I/O Operating Voltage (Max) (V) 1.9
Material Type Tested Packaged Device
Number of Reflow Cycles 3
32-bit Product Family Power Architecture
Core: Performance in MIPS 756
Leadtime (weeks) 8
Peak Package Body Temperature (PPT)(°C) 260
Pin/Lead/Ball Count 668
Ambient Operating Temperature (Min-Max) (°C) -40 to 105
Micron Size (μm) .13
Tape & Reel No
Description 8358 PBGA ENCRP
Application/Qualification Tier COMMERCIAL, INDUSTRIAL
Core: Number of cores (Spec) 1
Junction Operating Temperature (Max) (°C) 105
Life Cycle Description (code) PRODUCT RAPID GROWTH
Moisture Sensitivity Level (MSL) 3
Cache (kByte) 32
Device Type MPU
Minimum Package Quantity (MPQ) 36
RoHS Certificate of Analysis (CoA) Contact Us
Sample Exception Availability Y
USB USB 2.0
Core: Operating Frequency Max (Max) (MHz) 400
Harmonized Tariff (US) Disclaimer 8542.31.0000
Package Description and Mechanical Drawing PBGA-PGE 668 29SQ1.2P1.0
Bus Frequency (Max) (MHz) 133
Material Composition Declaration (MCD) Download MCD Report Download MCD Report

Freescale Semiconductor's MPC8360E PowerQUICC II™ Pro family of integrated communications processors is a next-generation extension of the popular PowerQUICC II line containing cores built on Power Architecture technology. The MPC8360E family incorporates a next-generation communications engine, the QUICC™ Engine, supporting a wide range of protocols, including Gigabit Ethernet and OC-12 asynchronous transfer mode (ATM)/Packet over Sonet (POS). Additional enhancements include the e300 core (enhanced version of the 603e™ core with larger caches), scaling up to 667 MHz, a DDR memory controller and the integrated security engine.

The MPC8360E PowerQUICC II Pro communications processor's advanced features make it suitable for today's and tomorrow's wired and wireless access equipment, as well as small and medium enterprise networking equipment. Target applications include multitenant units (MTUs), digital subscriber line access multiplexers (DSLAMs), wireless basestations, multi and fixed subscriber access nodes, add/drop multiplexers and routers.

The MPC8358E processor, a member of the MPC8360E PowerQUICC II Pro family, is pin-compatible with the MPC8360E (TBGA only). The MPC8358E offers a cost-effective, low-power processing solution that meets the performance requirements for broadband access applications, such as small-to-medium enterprise (SME) routers, low-end DSLAMs and IP private automatic branch exchange (PABX) systems.

e300 System-on-a-Chip Platform
The MPC8358E PowerQUICC II Pro family is based on the e300 system-on-a-chip (SoC) platform. This makes it easy and fast to add or remove functional blocks and develop additional SoC-based family members for emerging markets. At the heart of the e300 SoC platform is Freescale's e300 core built on Power Architecture technology. The e300 core is an enhanced version of the 603e core used in previous-generation PowerQUICC II processors.

Enhancements include twice as much L1 cache (32 KB data cache and 32 KB instruction cache) with integrated parity checking and other performance-enhancing features. The e300 core is software-compatible with existing 603e core-based products.

Connectivity
The MPC8360E processor is designed to support a wide range of communications interfaces, such as MII, RMII, GMII, TBI, RTBI, NMSI, UTOPIA, POS and TDM. The DDR memory controller helps to ensure high-speed memory access and a local system bus operating up to 133 MHz. Additional system connectivity is supplied by dual UART, dual inter-integrated circuit (I2C), dual serial peripheral interface (SPI), PCI interfaces and Universal Serial Bus (USB) interface (USB 2.0 full-/low-speed compatible).

Integrated Security The MPC8360E and MPC8358E processors feature integrated security with the powerful integrated security engine derived from Freescale's security coprocessor product line. Integrated security supports DES, 3DES, MD-5, SHA-1, AES and ARC-4 encryption algorithms, as well as a public key accelerator and an on-chip random number generator. The integrated security engine is capable of single-pass encryption and authentication, as required by IPsec, the IEEE® 802.11i standard and other security protocols.

Typical Applications
DSL infrastructure
  • DSLAMs
  • MTUs
Add/drop multiplexers and digital cross connects

Multiservice access nodes (MSAN)
Wireless infrastructure
